2K-Caster Steer

Industrial Trailers

Hamilton's robust line of heavy duty in-plant trailers, carts and trolleys guarantees the right towable equipment for your material handling needs. They are effortlessly rolling on our world class wheels and casters coupled together in trains with unyielding couplers and hitches providing years of service. Our trailers and carts are designed using the latest, state of the art 3D mechanical design software with simulation tools to ensure the most efficient use of raw materials. Hamilton leverages concepts like ergonomics, design for manufacture and assembly, continuous improvement and lean manufacturing to wring out waste giving you economical solutions to your materials handling needs. Flat out the best industrial trailers, factory carts, platform trucks, trolleys, dollies, and hand trucks available and shipped directly to your dock quickly.

  • Four Wheel Steer

    Used when towing long trains of carts through narrow factory aisles which require true-tracking service.

    See Products
  • Fifth Wheel Steer

    Economical trailer for moving large heavy duty loads like dies, tooling, metal plates, and structural steel bars.

    See Products
  • Caster Steer

    Trailer used for both towing and hand pushing, ideal for delivery of material from warehouse to shop floor.

    See Products
  • Auto Steer

    Workhorse cart that provides unrivaled utility by hauling loads with a high center of gravity and uneven loading....

    See Products

Caster-Steer Trailers

Capacity Range Up To 2000 lbs.

Overview
Fifth Wheel steer trailers feature steering that works like children’s little red wagons, but at a very adult level. These massively built industrial workhorses move extreme loads around plants and distribution centers. Generous steel decks deliver a robust surface for various loads. Front and rear axles are precisely located for optimal steering and load accommodation. Design trailers sized for specific loads and plant conditions such as load size, aisle widths, height requirements, and doorway widths.

Quality Features
A major wear point on any towed trailer is the towing loop. Hamilton uses forged steel loops, designed for handling the maximum towed load and resistant to wear during years of use.

Wheels are normally dual press-on Polyurethane tired wheels, which vary in diameter and width and can be specified for a trailer and its capacity. Tapered bearings, in some cases for 2” diameter axles, assure dependable rolling performance.

The fifth wheel assembly consists of massive ¾” steel plates sandwiching a UHMW disk, held together with a 2” diameter kingpin. Hamilton uses no shortcuts in this or any other critical part. The UHMW disk provides years of trouble-free service with very low turning resistance.

We use a 2” diameter or larger tongue axle connecting the tongue to the trailer framework. Recognizing the weight of the trailer and its load is concentrated on the tongue and tongue axle, Hamilton doesn’t skimp on this vital piece of hardware. The UHMW disk provides years of trouble-free service with very low turning resistance.

Each steel frame is custom designed for specific load and trailer size, assuring a good “match” between trailer and load.


To order or see more detail, click on suffix corresponding to desired wheel type & deck size.
Dimensions in inches
Platform
Size
Base
Model No.
SELECTION SUFFIXWeight
Lbs.
Duralast®Poly-Soft®Polylast™
Donut
Moldon
Rubber
